Phenolic Panels

  • Certification: Certified under UL181
  • Types of Phenolic Board: Phenolic Duct Board, Phenolic Exterior Wall Board
  • Maximum Temperature Resistance: Can withstand up to 180°C (356°F) consistently, with brief exposure up to 250°C (482°F)
  • Thickness: Customizable from 20-220 mm (0.8-8.7 inches)
  • Optional Surface Materials: Aluminum Foil, Color Steel
  • Compressive Strength: 190kPa
  • Thermal Conductivity: 0.019 W/(m·K)
Phenolic Panels​

Aluminum Foil Fabric

  • Heat Resistance: 550℃ (1000℉)
  • Thermal Radiation Reflectivity: 97%
  • Laminated Film: Aluminum Foil/Metallized Film/FR Aluminum Plating
  • Aluminum Foil Thickness: 7/14/18/25/36/50 microns
  • Width: 1m (3.28ft), 1.2m (3.94ft), 1.3m (4.27ft), 1.5m (4.92ft)
    Weight: 95g/sm (2.80oz/yd²), 110g/sm (3.25oz/yd²), 200g/sm (5.90oz/yd²), 430g/sm (12.68oz/yd²)
double sided aluminum foil fiberglass AL-110
Foil tape

Aluminum Foil Tape

  • Certification: UL181 Certified
  • Type of Tape: Aluminum Foil Tape, Aluminum Foil Fiberglass Cloth Tape
  • Maximum Temperature Resistance: 550℃ (1000℉)
  • Adhesive Type: Acrylic Pressure-Sensitive Adhesive, Silicone Glue, Flame-Retardant Adhesive
  • Applications: Suitable for pipe sealing, joint and seam bonding, automotive wiring harness wrapping, and prevention of electromagnetic interference, among others.
Fireproof Insulation Board(Steel Composite)

Magnesium Oxide Board

  • Certification: Certified under ASTM E84
  • Magnesium Oxide Board Types: Includes Magnesium Oxide Duct Board and Magnesium Oxide Exterior Wall Board
  • Temperature Resistance: Capable of withstanding temperatures from 800℃ (1472°F) to 1200℃ (2192°F)
  • Optional Surface Materials: Aluminum Foil, Color Steel
  • Weight: Ranges from 10kg-15kg (22-33 lbs)
  • Compressive Strength: ≥3000PA

CUSTOM SOLUTIONS

Our engineered systems team provides custom solutions through integrated design, prototyping, manufacturing and testing services. We can work with you and your team to develop and create custom solutions for any fire, smoke or heat challenge associated with your building, vessel or equipment.

HVAC SYSTEM

Phenolic air duct board composite insulation board with aluminum foil or color steel to enhance the thermal performance of the air duct

WALL INSULATION

Utilize the thermal insulation rate and flame retardant properties of phenolic or magnesium oxide to improve the thermal insulation performance of buildings.

VEHICLE ENGINEERING

Utilize the heat shielding and strength of aluminum foil wiring harness tape to improve vehicle wiring harness insulation performance.

WT Factory

About Us

Founded in 2002, WT Aluminum Foil Synthetic Materials Co., Ltd. has evolved into a premier innovator and manufacturer of thermal insulation composite materials. Situated in Jiangyin City, Jiangsu Province, our transition from a modest beginning to a renowned global enterprise reflects our commitment to excellence. The “WT” brand is celebrated for its quality and reliability, earning accolades both in domestic markets and internationally.

Service

WT offers globally competitive prices, superior quality adhering to ISO9001 standards, swift delivery through 75+ global freight lines, and expert 24/7 service teams.

Superior Quality

Adhering to the ISO9001 system, we ensure unwavering quality.

Expert Service

Our dedicated pre-sales, after-sales, and technical teams are available 24/7 to address all your needs.

Competitive Pricing

At WT, we offer globally competitive prices to drive your business growth.

Swift Delivery

With 75+ global freight lines, we guarantee timely deliveries.
